AMP Régie Flight Case A
So practical
From your front room to the middle of the desert, it will follow you everywhere !
6 SONY BVP E10 / E30 cameras
6 analogue or digital VTRs
6-channel servers
Specifications
Length : 4,00 m
Width : 2,60 m
- depending on configuration -
Dimensions : 5 to 8 racks 19''
Power : 380 V 32 A trip
Video
Video Miwer
- SONY DVS 7200 digital :
- 36 inputs
- 2 M/E with 2 linear keys
- 14 auxiliaries
- 2 DSK
- Double frame memory
Cameras
6 SONY BVP E10 / E30 cameras
Recording / Playback
- 6 analogue or digital VTRs
- 6-channel servers
Grids
- 16 x 16 SONY digital
Monitoring
- LCD 20'' EIZO
- SD mosaic image system
- SONY BVM 14'' SD
Video Device
- Writing generator, dual-channel S CHYRON
- SNELL & WILCOX embedders / disembedders / conversion / distribution
- Satellite demodulator reception and UHF
- Digital measurement HD WFM 701
Audio
Audio Mixing Desk
- YAMAHA DM 2000 digital :
- 24 mic/line inputs
- 16 analogue line inputs
- 24 AES inputs / outputs
- 1 stereo ouput
- 8 groups
- 12 auxiliaries
- 4 matrixs
OR
- YAMAHA O2R digital :
- 24 inputs
- 8 groups
- 6 auxiliaries
- 1 stereo output
Monitoring
- GENELEC 1029A YAMAHA MSP5 sound monitor
Audio Device
- CD player
- Delay and reverb effects
Set of microphone
Intercom
- RTS/TELEX Zeus 24 x 24 matrix
- 2-wire RTS 2-channel interfaced system
- 2 telephone hybrids
- 1 RNIS codec
- Talkies (technical)
- 1 4-wire RF
