AMP Régie Flight Case HD

Vidéo

Video mixer

• SONY MVS 8000a SF SD/HD :
  • 34 inputs / 24 outputs
  • 2 M/E with 8 linear keys + chroma key and assignable brightness per M/E
  • 2 M/E desks 16 direct access
  • Library of still or live images, 8 channels

Cameras

6 SONY HDC 1500 cameras

Recording / Playback

• 6 analogue or digital video recorders
• 6-channel server

Grilles

• 16 x 16 SONY HD SDI / SD SDI

Monitoring

• LCD 20'' EIZO
• HD/SD mosaic image system
• SONY BVM 14'' HD/SDI

Périphériques vidéo

• 1 Writing generator, dual channel SD/HD CHYRON
• SNELL & WILCOX Embedders / disembedders / conversion / distribution
• Satellite demodulator reception and UHF
• HD WFM 701 digital measurement

Audio

Audio mixing desk

• YAMAHA DM 2000 digital :
  • 24 mic/line inputs
  • 16 analogue line inputs
  • 24 AES inputs/outputs
  • 1 stereo output
  • 8 groups
  • 12 auxiliaries
  • 4 matrixs

Or

• YAMAHA O2R digital :
  • 24 inputs
  • 8 groups
  • 6 auxiliaries
  • 1 stereo output

Monitoring

• GENELEC 1029A YAMAHA MSP5 monitoring

Audio device

• CD player
• Effects: reverb and delay

Set of microphone

Interphonie

• RTS/TELEX Zeus 24 x 24 matrix
• 2 2 -wire RTS interfaced
• 2 hybrids telephone
• 1 RNIS codec
• Talkies (technical)
• 1 4-wire RF
