SOFT BROADCAST OB Van 3S
So practical
Foolproof versatility !
8 THOMSON TTV 1657 cameras
6-position VTRs
STUDER 963 28/8/4 sound monitor
Specifications
OB Van
Porter 16 t
Length : semi : 9,50 m
Width : extension closed : 2,55 m
Heigth : 3,80 m
Registration : AK-548-WF
Power : 380 V tri, neutral (P17 - 63 A outlet)
Consumption : 60 KVA
Support van
Porter 19 t
Registration : AK-580-WF
Vidéo
Video mixer
- SONY DVS 600 digital :
- 24 inputs
- 2 (M/E coupled)
- 6 auxiliaries
- 16 buttons
- 2 M/E linear keys including 1 chroma key
- 2 Dvx 2D
- DME 300 3D digital effects generator
Cameras
- 4 to 8 THOMSON TTV 1657 4/3 - 16/9 cameras
- ANGENIEUX 15x-40x-62x-GA lenses
Playback / Recording
- 6-position VTRs
- Spaces for 2 slow-motion operators
Grids
- LEITCH 16x16
Video device
- Writing generator
- Converters + distribution
- THOMSON & SNELL
- SNELL& WILCOX synchronisers
- TEKTRONIC WF 601 digital measurement
Audio
Audio mixing desk
- STUDER 963 28/8/4 desk
- 28 inputs
- 8 groups
- 4 PGM mono outputs
Monitoring
- CABASSE
Audio device
- CD K7 DAT sources effects
- Dynamic : limiters / compressors
- Effects : delay / reverb
Set of microphone
Intercom
- 4- wire TELEX ADAM CS digital system
- I2-wire RTS intercom
- STUDER hybrid telephones
- MOTOROLA walkie-talkie base (technical)
- Codecs AETA Scoop
