VISUAL TV OB Van D
Comfortable
Van mobility, fixed control room space !
14 SONY BVP E30 digital cameras
8 digital or analogue VTRs
5 6-channel video servers (or 5 recorders)
Specifications
VOLVO 38 t
Lengths :
semi : 12.00 m
with towing vehicle: 15.00 m
Widths :
fully expanded : 4.50 m
fully closed : 2.50 m
Height : 4 .00 m
Registrations :
OB van : AE-631-LS
towing vehicle : 638 BMY 44
Power :
380 V Tri and neurtral
63 A (Marechal 63 A plug)
Consumption : 70 KVA
Support van
VOLVO FL7
Registration : 339 AVJ 44
Video
Video Mixer
- BTS DD35 Xtend digital
- 48 inputs
- 4 M/E (M/E coupled), 32 direct access
- 15 auxiliaries
- 12 linear keys including 2 chroma keys
- 4 ramcorders 2 Dvx 2D
- Dual-channel effects generator PINNACLE DV Extreme
Cameras
- 12 SONY BVP E30 cameras
Recording / Playback
- 8 analogue or digital video recorders
- 5 6-channel servers (or 5 VTRs)
- Spaces for 5 slow-motion operators
Grids
- 64 x 64 SD BTS SDI
- 64 x 80 PAL BTS PAL
Monitoring
- SONY 9"/14" PAL SDI
- UMD Source display
- Red/Green source displays
Video Device
- Writing generator, dual-channel SD
- ART converters + distribution
- SNELL & WILCOX synchronisers
- Digital measurement TEKTRONIC WF 601
Audio
Audio Mixing Desk
- STUDER Vista 5 numérique
- 42 faders
- 88 inputs
- 72 outputs
- MADI interfaces
Grids
- 96 x 64 BTS Vénus
Monitoring
- Sound monitor GENELEC
Audio Device
- Effects / Finalizer TC Electronik M 2000
- Digital audio workstation on PC 8 channels
Intercom
- 4-wire RTS / TELEX Adam CS (64 x 64) digital
- 2-wire RTS 6-channel
- PROSPECT 12 x 12 mixer
- MOTOROLA walkie-talkie network (technical)
- 2 hybrid telephones
- AETA Scoop codecs
- 1 AEQ Digital loop player
