VISUAL TV OB Van E
General-purpose
A concentrated of experience in a small volume
8 SONY BVP E30 digital cameras
6 digital or analogue VTRs
2 6-channel video servers (or 2 recorders)
Specifications
Type : Renault 19 t
Length : 10.5 m
Widths :
fully expanded : 3.30 m
fully closed : 2.50 m
Height : 4.00 m
Registration : 906 FXA 92
Power : 380 V Tri
(1 P17 63 A)
Consumption: 45 KVA
Support van
Type : VOLVO FM7 290
Registration : 919 FXA 92
Video
Video Mixer
- BTS DD30 digital
- 32 inputs
- 3 M/E 24 buttons
- 10 auxiliaries
- 8 linear keys including 2 chroma keys
- Dual-channel effects generator PINNACLE DV Extreme
Cameras
- 8 SONY BVP E30 cameras
Recording / Playback
- 6 analogue or digital video recorders
- 2 6-channel servers (or 2 VTRs)
- Spaces for 3 slow-motion operators
Grids
- 48 x 48 BTS SDI
Monitoring
- SONY 9"/14" PAL SDI
Video Device
- Dual-channel writing generator
- ART converters + distribution
- SNELL & WILCOX synchronisers
- Digital measurement TEKTRONIC WF 601
Audio
Audio Mixing Desk
- STUDER 963 digital
- 32 inputs
- 8 groups
- 4 outputs
Grids
- 32 x 32 BTS
Monitoring
- Sound monitor GENELEC
Audio device
- Effects YAMAHA Rane
- Digital audio workstation on PC 8 channels
Intercom
- 4-wire TELEX Chronus (48x48)
- 2-wire RTS 6-channel interfaced system
- PROSPECT 6 x 6 mixer
- MOTOROLA walkie-talkie network (technical)
- 1 telephone hybrid
- AETA Scoop codec
