Visual TV OB Van RF
A future concept
When cables will be useless...
15 RF receptions
5 cameras
4 digital or analogue VTRs
1 6-channel video servers (or 1 recorder)
Specifications
Semi 16 t
Length : 12.00 m
Width : 2.00 m
Height : 4.00 m
Registrations :
semi : AE-470-LS
towing vehicule: AE-720-LS
Power: 380 V Tri 45 KWA
Video
Video Mixer
- SONY MVS 6000
- 32 inputs / 24 outputs
- Panel compact 12 buttons + shotbox
- 2 M/E (M/E coupled)
- 8 linear keys
- 2 DVE 3D
Cameras
- 5 SONY BVP E30 / LDK 500 / THOMSON 1657 cameras
Recording / Playback
- 4 digital or analogue video recorders
- 1 6-channel server (or 1 VTR)
- Space for 1 slow-motion operator
Grids
- 96 x 96 BTS SDI
Monitoring
- LCD 24" SD
- Mosaic image systems
Video device
- Writing generator, dual-channel SD
- PROBELL converters + distribution
- SNELL & WILCOX synchronisers
- Digital measurement TEKTRONIC WF 601
Audio
Audio Mixing Desk
- YAMAHA DM1000
- 16 inputs
- 10 outputs
Grids
- 64 x 64 BTS
Monitoring
- Sound monitor YAMAHA
Audio Device
- Effects processing with TC ELEC>TRONIC M 2000
- Digital audio workstation on PC for 8 channels
RF
- 15 RF receptions
- 1 auto tracking
- GPS mobiles positioning
- Spectrum analizer
- Optical/RF converter
- 1 17 meters pole
- 1 15 meters pole
Intercom
- CLEARCOM Matrix +3 48 x 48
- 2-wire RTS 6-channel system
- PROSPECT 6 x 6 program unit
- MOTOROLA walkie-talkie network (technical)
- 1 hybrid telephone
- AETA Scoop codecs
