VISUAL TV The Enterprise
The flagship
Nobility in the soul !
30 SONY HDC 1500 cameras
10 digital or analogue VTRs
8 6-channel video servers (or 8 recorders)
Specifications
Volvo FH 12 38 t
Lengths :
semi : 13.90 m
with towing vehicle : 16.50 m
Widths :
fully expanded : 5.20 m
one opended extension : 4.50 m
fully closed : 2.50 m
Height : 4.05 m
Registrations :
OB van : AE-558-LS
Towing vehicle : AA-052-QJ
Power : 380 V Tri (2 Marechal 63 A
or 1 Marechal 125 A)
Support van
Volvo FH 12 38 t
Length : 16.50 m
Width : 2.55 m
Height : 4.00 m
Registrations :
Towing vehicle : 818 BMZ 44
Semi :AE-516-LS
Video
Video Mixer Control Room 1
- Kayak GRASS VALLEY digital SD/HD
- Xtend DD 32 buttons control panel
- 96 inputs / 48 outputs
- 4,5 M/E
- 12 auxiliaries per M/E via Coco
- 20 linear keys including 4 chroma keys
- 8 ramcorders 80s in HD 180s in SD
- 7 internal DVE, 4 external DVE
Video Mixer Control Room 2
- Kayak GRASS VALLEY digital SD/HD
- Kayak DD 24 buttons control panel
- 48 inputs / 24 outputs
- 2,5 M/E
- 12 auxiliaries per M/E via Coco
- 12 linear keys including 2 chroma keys
- 6 ramcorders 80s in HD 180s in SD
- 8 internal DVE
Cameras
- 30 SONY HDC 1500 fibre or triax CU connections cameras
Recording / Playback
- 10 analogue or digital video recorders
- 8 6-channel servers (or 8 VCRs)
- Spaces for 8 slow-motion operators
Grids
- 384 x 480 GVG Trinix HD/SD
Monitoring
- SONY 9"/14" PAL SDI
- UMD source display
- Red/green displays
Video Device
- Writing generator, dual-channel SD/HD
- SNELL & WILCOX Multi-format synchronisers
- Embedders / disembedders
- Cross conversion
- HD digital measurement WFM series 7000 et 5000
Audio
Audio Mixing Desk
- STUDER VISTA 8 Digital :
- 52 faders
- 2 stage boxes 56 mics / fibre connection
- YAMAHA DM 1000 digital auxiliary mixing desk
Grids
- 254 x 256 Internal AES STUDER VISTA 8 mixing desk
Monitoring
- Sound control room : 5.1 DYNAUDIO air 15, Air base et Bm6 monitors
- Production control room : 5.1 GENELEC series 8000 monitoring
Audio Device
- Effects processing with TC ELECTRONIC M6000
- Digital audio workstation on PC for 8 channels
- Coding/Deconding Dolby E, Dolby Prologic coding
Intercom
- 4-wire digital TELEX Adam 96 x 96 system
- 2-wire RTS 6-channel system
- PROSPECT 12 x 12 program unit
- MOTOROLA walkie-talkie network (technical)
- 2 telephone hybrids
- AETA Scoop codecs
