Studio Gabriel Régie HD

Mélangeur vidéo

  • SONY MVS 8000g numérique HD/SD
  • Générateur d'effets SONY MVE 8000a 4 canaux ou SONY DME 7000 bi-canal

Caméras

  • 10 caméras SONY HSC 300 dont une tête débrochée

Console audio

  • STUDER VISTA 8
  • YAMAHA DM1000



Studio-Gabriel-Monitoring

Video

Vision Mixer
  • SONY MVS 8000g digital HD/SD
    • 34 inputs / 24 outputs
    • 3 M/E with 8 incrustateurs linéaires
    • Library of still or live images 8 channels
    • 1 mixing desk 3 M/E 32 buttons
  • SONY MVE 8000a 4-channel effects generator or SONY DME 7000 dual channel

Routers
  • 64 x 64 SONY digital video
  • 64 x 64 SONY analogue

Monitoring
  • HD SDI / SD SDI / PRO-BEL 96 x 192 Multi-standard video
  • Controller VSM Studio

Cameras
  • 10 SONY HSC 300 cameras

Recording
  • Until 8 multi format VTRs
  • 1 6-channel EVS XT2 server
  • 1 4-channel EVS XS server
  • Ingest simultanée sur AVID UNITY
  • 6 DVD Player/Recorder

Video devices
  • 1 SD/HD AVID DEKO 1000 dual channel writing generator
  • Multi format synchronisers
  • Embedders / disembedders
  • Down-converters / Up-converters
  • Cross conversion
  • Satellite demodulator reception
  • HD WFM serie 5000 RON digital measurement


Sound

Audio Mixer
  • STUDER VISTA 8
    • 52 faders
    • 56 MIC / LINE inputs
    • 44 AES inputs
    • 34 analogue outputs
    • 44 AES outputs
  • YAMAHA DM1000
    • 16 faders + 16 IN / OUT AES + 8 IN / OUT analogue

Router
  • Internal VISTA 8 STUDER 144 x 128 AES mixing desk

Monitoring
  • Multi-channel sound monitor DYNAUDIO in sound and video production
  • WHOLER + FOSTEX monitoring

Audio devices
  • Coding/decoding DOLBY E / AUDIO TOOLS
  • CD / DAT / MD Player and audio server
  • Multi-effect processing with TC-ELECTRONIC M 6000 + M 3000
  • Digital video workstation on PC SOUNDFORGE
  • Finalizer Junger B41
  • Set of microphone (on customer request)



Intercom

  • 64 x 64 CLEARCOM matrix
  • Networks 2 interfaced RTS wires 6 channels
  • 2 hybrid telephones
  • 2 RNIS codecs
  • 1 MOTOROLA walkie-talkie network (technical)
  • 1 double HF OVERLINE network
  • HF PHONAK headset monitor

Système de montage

3 salles de montage équipées de

  • stations MEDIA COMPOSER NITRIS DX
  • Consoles audio MACKIES
  • Ecoutes GENELEC
  • Serveur UNITY 2 x 8 to
  • Gestion workflow INTERPLAY
  • INGEST 5 flux via serveur


* selon configuration
